Default Fikse wheel face color change?

I have never taken apart a multi piece wheel before, but I was thinking of making a color change to the center section of my rims. I have tried to get in touch with Fikse but had no luck with anyone calling me back. Any advice or input on doing this? Thanks.


__________________
69 SS396 Camaro Coupe, 4link, 12bolt posi, Speedtech LCA and UCA's, Hotchkis 2" drop springs and sway bar, Ridetech triple remote resevoir coilovers, Bilsteins, Wilwood 6 piston front/4 piston rear, Magnaflow stainless exhaust, Lemons Headers, Comp rollers/p-rods/cam, Fikse 18x8.5 and 18x10
Reply With Quote
  #2
Old 07-18-2012, 05:09 PM
JMitch19's Avatar
JMitch19 JMitch19 is offline
Senior Member

Join Date: Feb 2005
Location: Caledonia,MI
Posts: 406
Thanks: 0
Thanked 4 Times in 2 Posts
Default

Paul Van Nus painted the centers of his Fikses. I'm not sure what the process was, but you might want to get a hold of him at Dutchboy Restorations.
__________________
Jason Mitchell

1971 Camaro 416 LT1 Project
Reply With Quote
  #3
Old 07-19-2012, 10:39 AM
rjsjea's Avatar
rjsjea rjsjea is offline
Senior Member

Join Date: Sep 2007
Location: Oregon
Posts: 667
Thanks: 0
Thanked 1 Time in 1 Post
Default

I just did a set, followed this video from CCW. Used the torque specs from my wheel manufacturer. Best part is.....it worked the first time!!

http://www.ccwheel.com/incs/technica...air_video.html
__________________
RobS
71 Demon, AlterK - 4 link GenIII hemi conversion
66 Rambler Classic Wagon, LS conversion -Scott's IFS/4bar-bagged
Reply With Quote
  #4
Old 07-19-2012, 01:36 PM
Jano4's Avatar
Jano4 Jano4 is offline
Member

Join Date: Mar 2010
Location: Chicago, IL
Posts: 68
Thanks: 0
Thanked 0 Times in 0 Posts
Default

I'm sure the video above covers everything. But in general. Remove the tires. Unbolt all the inside nuts. Cut the silicone to separate the 2 half's of the barrel. I believe the face can now be removed.
__________________
2000 Chevrolet Camaro Z28

Last edited by Jano4; 07-19-2012 at 01:48 PM.
Reply With Quote
  #5
Old 07-22-2012, 09:12 PM
19,69camaro 19,69camaro is offline
Member

Join Date: Feb 2010
Posts: 69
Thanks: 0
Thanked 0 Times in 0 Posts
Default

I hope its some other form of black because those look great as they are.
Reply With Quote
  #6
Old 07-22-2012, 09:53 PM
67XR7's Avatar
67XR7 67XR7 is offline
Senior Member

Join Date: Nov 2011
Location: Sf, Bay Area
Posts: 390
Thanks: 5
Thanked 10 Times in 7 Posts
Default

Fikse didnt get back to you? never heard of them having bad customer service!
__________________
1970 Z28, Pm me if interested in wheel tool rental
Reply With Quote
  #7
Old 07-23-2012, 09:28 AM
g356gear's Avatar
g356gear g356gear is offline
Senior Member

Join Date: Oct 2008
Posts: 660
Thanks: 0
Thanked 8 Times in 2 Posts
Default

Quote:
Originally Posted by rjsjea View Post
I just did a set, followed this video from CCW. Used the torque specs from my wheel manufacturer. Best part is.....it worked the first time!!

http://www.ccwheel.com/incs/technica...air_video.html
Thanks for the links. I wonder if you have to re-do the silicone after the center is unbolted or if you can just remove the center and leave the center hoops together.
__________________
69 SS396 Camaro Coupe, 4link, 12bolt posi, Speedtech LCA and UCA's, Hotchkis 2" drop springs and sway bar, Ridetech triple remote resevoir coilovers, Bilsteins, Wilwood 6 piston front/4 piston rear, Magnaflow stainless exhaust, Lemons Headers, Comp rollers/p-rods/cam, Fikse 18x8.5 and 18x10
Reply With Quote
  #8
Old 07-23-2012, 11:36 AM
will69camaro will69camaro is offline
Lateral-g Supporting Member

Join Date: Dec 2004
Location: Houston
Posts: 1,479
Thanks: 268
Thanked 185 Times in 101 Posts
Default

The barrel has to come apart to get the wheel out. I disassembled my FM5's and this was the case anyway. If I was home I'd take some pictures of them apart so you could see but I am away from the house.

I like the way they look now. Only issue with black anodizing is in the sun some of them have been known to turn purple...Ask me how i know
__________________
Texas A&M BSME 2008
1969 Camaro - Hugger Orange
1969 C10 SWB - Hugger Orange
1992 Corvette ZR-1
2021 Ford F250 Tremor
Reply With Quote
  #9
Old 07-25-2012, 09:22 AM
Sales@Dutchboys's Avatar
Sales@Dutchboys Sales@Dutchboys is offline
Lateral-g Supporting Vendor

Join Date: Jan 2006
Posts: 2,163
Thanks: 3
Thanked 35 Times in 22 Posts
Default

Like Jason said. I just did my fikses and didn't remove tires or split the wheel halves.
With all the bolts out, the center won't just fall out. Take a dead blow and lightly tap around it and they will fall right out.
Then when you put them back together just red loctite and torque to your specs.
__________________
dutchboyshotrods.com
269-823-2967

https://www.facebook.com/Dutchboyshotrods
Reply With Quote
  #10
Old 07-27-2012, 10:43 AM
g356gear's Avatar
g356gear g356gear is offline
Senior Member

Join Date: Oct 2008
Posts: 660
Thanks: 0
Thanked 8 Times in 2 Posts
Default

Quote:
Originally Posted by DutchBoys View Post
Like Jason said. I just did my fikses and didn't remove tires or split the wheel halves.
With all the bolts out, the center won't just fall out. Take a dead blow and lightly tap around it and they will fall right out.
Then when you put them back together just red loctite and torque to your specs.
Anyone know what the torque specs are for Fikse wheels?
__________________
69 SS396 Camaro Coupe, 4link, 12bolt posi, Speedtech LCA and UCA's, Hotchkis 2" drop springs and sway bar, Ridetech triple remote resevoir coilovers, Bilsteins, Wilwood 6 piston front/4 piston rear, Magnaflow stainless exhaust, Lemons Headers, Comp rollers/p-rods/cam, Fikse 18x8.5 and 18x10
Reply With Quote
